| Place of Origin: | Jiangxi, China |
|---|---|
| Brand Name: | DEC |
| Certification: | RoHS |
| Model Number: | OSPS30150CW |
| Minimum Order Quantity: | 1000PCS |
| Price: | Negotiated |
| Packaging Details: | Boxed |
| Delivery Time: | 1 - 2 Weeks |
| Payment Terms: | Telegraphic Transfer in Advance (Advance TT, T/T) |
| Supply Ability: | 15,000,000PCS Per Day |
| Type: | Schottky Diode | Repetitive Peak Reverse Voltage: | 100V |
|---|---|---|---|
| Working Peak Reverse Voltage: | 100V | Maximum DC Blocking Voltage: | 100V |
| Maximum Average Forward Rectified Current Total Device: | 40A | Operating Junction Temperature Range: | -65~150 ℃ |
| Storage Temperature Rang: | -65~175 ℃ | Peak Forward Surge Current: | 400A |
| High Light: | surface mount schottky diode,small signal schottky diode |
||
High Speed Schottky Signal Diode With High Switching Frequency
chottky Signal Diode Features:
High switching frequency
Low forward voltage drop
High efficiency and low power loss
High volume of current and good capability of surge current
chottky Signal Diode Applications
High frequency rectifier of switching mode power supplies
Freewheeling diodes
Polarity protection application
DC-DC converters
Absolute Maximum Ratings (Tc=25°C)
| Type: | Schottky Diode | Repetitive Peak Reverse Voltage: | 100V |
|---|---|---|---|
| Working Peak Reverse Voltage: | 100V | Maximum DC Blocking Voltage: | 100V |
| Maximum Average Forward Rectified Current Total Device: | 40A | Operating Junction Temperature Range: | -65~150 ℃ |
| Storage Temperature Rang: | -65~175 ℃ | Peak Forward Surge Current: | 400A |
