| Place of Origin: | Jiangxi, China |
|---|---|
| Brand Name: | DEC |
| Certification: | RoHS |
| Model Number: | OSPS30200CW-2 |
| Minimum Order Quantity: | 1000PCS |
| Price: | Negotiated |
| Packaging Details: | Boxed |
| Delivery Time: | 1 - 2 Weeks |
| Payment Terms: | Telegraphic Transfer in Advance (Advance TT, T/T) |
| Supply Ability: | 15,000,000PCS Per Day |
| Type: | High Voltage Schottky Diode | Repetitive Peak Reverse Voltage: | 100V |
|---|---|---|---|
| Working Peak Reverse Voltage: | 100V | Maximum DC Blocking Voltage: | 100V |
| Maximum Average Forward Rectified Current Total Device: | 40A | Operating Junction Temperature Range: | -65~150 ℃ |
| Storage Temperature Rang: | -65~175 ℃ | Peak Forward Surge Current: | 400A |
| High Light: | surface mount schottky diode,small signal schottky diode |
||
Small Size High Voltage Schottky Diode / Freewheeling Schottky Diode Smd
High Voltage Schottky Diode Features:
The plastic package carries Underwriters Laboratory
Flammability Classification 94V-0
Idea for printed circuit board
High forward surge current capability
High temperature soldering guaranteed
High Voltage Schottky Diode Applications
High frequency rectifier of switching mode power supplies
Freewheeling diodes
Polarity protection application
DC-DC converters
Absolute Maximum Ratings (Tc=25°C)
| Type: | High Voltage Schottky Diode | Repetitive Peak Reverse Voltage: | 100V |
|---|---|---|---|
| Working Peak Reverse Voltage: | 100V | Maximum DC Blocking Voltage: | 100V |
| Maximum Average Forward Rectified Current Total Device: | 40A | Operating Junction Temperature Range: | -65~150 ℃ |
| Storage Temperature Rang: | -65~175 ℃ | Peak Forward Surge Current: | 400A |
