| Place of Origin: | Jiangxi, China |
|---|---|
| Brand Name: | DEC |
| Certification: | RoHS |
| Model Number: | MBRF30200DT- |
| Minimum Order Quantity: | 1000PCS |
| Price: | Negotiated |
| Packaging Details: | Boxed |
| Delivery Time: | 1 - 2 Weeks |
| Payment Terms: | Telegraphic Transfer in Advance (Advance TT, T/T) |
| Supply Ability: | 15,000,000PCS Per Day |
| Name: | Schottky Signal Diode | Repetitive Peak Reverse Voltage: | 100V |
|---|---|---|---|
| Working Peak Reverse Voltage: | 100V | Maximum Average Forward Rectified Current Total Device: | 30A |
| Peak Forward Surge Current: | 400A | Operating Junction Temperature Range: | -65~150 ℃ |
| Storage Temperature Rang: | -65~175 ℃ | Type: | Surface Mounted |
| High Light: | surface mount schottky diode,small signal schottky diode |
||
Surface Mounted Schottky Signal Diode High Forward Surge Current Capability
Schottky Signal Diode Features:
For surface mounted applications
. Metal silicon junction,majority carrier conduction
. Low power loss,high efficiency
. Built-in strain relief,ideal for automated placement
. High forward surge current capability
. High temperature soldering guaranteed:250℃/10 seconds at terminals
. The plastic material carries U/L recognition 94V-O
Schottky Signal Diode Applications
Schottky Signal Diode are used for signal-routing tasks, Metallurgically Bonded Construction , rail-to-rail protection and RF applications, such as balanced mixers and demodulators. Devices above 100 mA enter the converter application field with rectification tasks, or discrete OR-ing function.
Absolute Maximum Ratings (Tc=25°C)
| Name: | Schottky Signal Diode | Repetitive Peak Reverse Voltage: | 100V |
|---|---|---|---|
| Working Peak Reverse Voltage: | 100V | Maximum Average Forward Rectified Current Total Device: | 30A |
| Peak Forward Surge Current: | 400A | Operating Junction Temperature Range: | -65~150 ℃ |
| Storage Temperature Rang: | -65~175 ℃ | Type: | Surface Mounted |
